TDS or Spectra Precision Survey Pro
Conversion:
TDS (.RAW) or (.RW5) files can be imported using the GPS Data Importer.
Import Steps:
- Ensure your project is defined as a Grid Proect and that the coordinate system has been selected
- Import Spectra Precision Vectors directly into a STAR*NET project via: Input | Import GPS Vectors | Import
- Select TDS Survey Pro GPS or Job xml from the pulldown menu
- Browse to your .rw5 or .jxl file
- Pick "Import!"
- To see your result double pick on the new ".gps" file that has been added to your Data Input Files panel:
Notes:
See this article explaining data exchange between MicroSurvey CAD and STAR*NET.
